1. Action force: 700+/-50gf
2. Key type: self-locking button
3. Rated current: 0.1A
4. Rated voltage: 1A
5. Contact resistance: less than or equal to 200MΩ
6. Ambient temperature: -25 to 70 degrees Celsius
7. Material: POM
8. Spring: 65MN
9. Stretching piece: H65M
10. SMD feet: brass
11. Scope of application: Button switches are commonly used in audiovisual products, digital products, remote controls, household appliances, electronic toys, medical equipment
Specification:
|
Package Weight
|
| One Package Weight |
0.05kgs / 0.12lb
|
| Carton Weight |
27.00kgs / 59.52lb
|
| Carton Size |
90cm * 90cm * 89cm / 35.43inch * 35.43inch * 35.04inch
|
| Loading Container |
20GP: 36 cartons * 324 pcs = 11664 pcs
40HQ: 85 cartons * 324 pcs = 27540 pcs
|
|
