Features1. Measure thickness of surface coatings on metal substrates
2. Single/continuous/differential measurement available
3. Zero-point/2-point/basic calibration available
4. Metric and imperial units of measurement optional
5. Powered by 2 x 1.5V AAA batteries
6. LCD backlight
7. Auto power off
Specifications1. Measuring range: 0 - 1.80mm (0 - 71.0 mil)
2. Resolution: 0.01mm/1mm
3. Measurement error: +-0.03mm
4. Min diameter of substrate: 50mm
5. Min thickness of substrate: 0.5mm
6. Operating temperature: 0 - 40 celsius degree
7. Operating humidity: 10% - 95% relative humidity
Specification:
|
General
|
| Weight |
58g (without batteries) |
|
|
Package Weight
|
| One Package Weight |
0.17kgs / 0.37lb
|
| Carton Weight |
6.60kgs / 14.55lb
|
| Carton Size |
62cm * 42cm * 34cm / 24.41inch * 16.54inch * 13.39inch
|
| Loading Container |
20GP: 301 cartons * 40 pcs = 12040 pcs
40HQ: 699 cartons * 40 pcs = 27960 pcs
|
|
