1) Voltage: DC 12V-24V
2) Current: <= 8A
3) Output: 1 channel
4) Sensing distance: 5-8m
5) Static power consumption: <1W
6) Material: plastic
7) Size: 88mm (L) x 60mm (W) x 35mm (H)
8) Direction for Use:
-Connect the load wire at first, following by the power wire; please ensure short circuit cannot occur between connecting wire before you turn on the power.
-When detected someone the light turn on, when people left 10 seconds, the light turn off.
-Should connect the right control signal output line and input line
Specification:
|
Package Weight
|
| One Package Weight |
0.11kgs / 0.24lb
|
| Carton Weight |
10.60kgs / 23.37lb
|
| Carton Size |
38cm * 33cm * 33cm / 14.96inch * 12.99inch * 12.99inch
|
| Loading Container |
20GP: 644 cartons * 100 pcs = 64400 pcs
40HQ: 1495 cartons * 100 pcs = 149500 pcs
|
|
