Functions:
1. Two-way intercom and unlock function.
2. Two-core wire connection, four-core wire connection with unlock.
3. The door machine is surface-mounted design and easy to install.
4. Using new ABS plastic, durable.
5. There is an excellent side tone cancellation circuit, and the intercom sound is clear.
6. Effective intercom distance is more than 100 meters.
7. Easy installation, users can install it by themselves.
Power parameters:
1. Audio undistortion rate> = 50mW
2. Talk time: unlimited, free call
3. Power adapter input voltage: AC 220V 50Hz
4. Power adapter output voltage: AC 12V 1200mA
5. Frequency response: 300-3400Hz +/- 3dB
6. Working voltage: DC 12V +/- 10%
7. Power consumption: static <0.2W, call status <2W
8. Installation: Hands-free wall mount
9. Indoor extension size: 227x87x45mm
10. Door machine size: 100x36x73mm
Specification:
|
Package Weight
|
| One Package Weight |
0.61kgs / 1.35lb
|
| Carton Weight |
13.00kgs / 28.66lb
|
| Carton Size |
42cm * 50cm * 37cm / 16.54inch * 19.69inch * 14.57inch
|
| Loading Container |
20GP: 343 cartons * 20 pcs = 6860 pcs
40HQ: 796 cartons * 20 pcs = 15920 pcs
|
|
