1. Operating voltage range: DC voltage 5-20V
2. Static current: <65uA
3. Level output: 3.3 V high / low 0V
4. Trigger mode: L non-repeatable trigger / H repeat trigger (default repeat trigger)
5. Delay time: 0.5-200S (adjustable) can be made in the range of a few seconds - tens of minutes
6. Blocking time: 0.2S can be made in the range of a few seconds - tens of seconds
7. Circuit board dimensions: 32mm*24mm
8. Sensing range: <120 degree cone angle, in 7m
9. Working temperature: -15-+70 degrees
10. Induction lens size: diameter: 23mm
Specification:
|
Package Weight
|
| One Package Weight |
0.03kgs / 0.06lb
|
| Carton Weight |
14.00kgs / 30.86lb
|
| Carton Size |
63cm * 39cm * 23cm / 24.8inch * 15.35inch * 9.06inch
|
| Loading Container |
20GP: 471 cartons * 510 pcs = 240210 pcs
40HQ: 1095 cartons * 510 pcs = 558450 pcs
|
|
