1. It applies mobile products to supporting the use, and suited to outdoor work environments.
2. It has small size, light weight, reliable performance, simple to connect, easy to use.
3. Low operating costs (no ribbons, ink cartridges).
4. Applications: the mobile police system, the tobacco distribution system, the utility meter reading system, the mobile office / mobile logistics systems, the portable instrumentation, the testing equipment, ancillary equipment.
5. Print speed: 90mm / sec
6. Reliability TPH life: 100km
7. Resolution: 203DPI (8dot/mm)
8. Printing width: 48mm (384dot)
9. Paper width: 58+-01mm
10. Roll diameter: <=40mm
11. Paper type: thermal paper
12. Print parameters: support to download the Logo trademark
13. Charging mode: DC 9V/1.5A
14. Lithium battery: 7.4V, 1500mA
Specification:
|
General
|
| Printer Type |
Thermal Printer |
| Printing Method |
Thermal line printing |
| Interface |
Standard RS232/USB, Bluetooth 2.0/SPP agreement or infrared/IRCOMM agreement |
|
|
Work Environment
|
| Working Temperature |
-10 to 50 Degrees |
|
|
Package Weight
|
| One Package Weight |
0.47kgs / 1.04lb
|
| Carton Weight |
18.04kgs / 39.77lb
|
| Carton Size |
35cm * 30cm * 24cm / 13.78inch * 11.81inch * 9.45inch
|
| Loading Container |
20GP: 1058 cartons * 40 pcs = 42320 pcs
40HQ: 2456 cartons * 40 pcs = 98240 pcs
|
|
