1. Fully compliant with PCI Express Base Specification Revision 2.0.
2. Single-lane (x1) PCI Express throughput rates up to 5Gbps.
3. Compliant with Universal Serial Bus 3.0 specification Revision 1.0.
4. Support simultaneous operation of multiple USB 3.0, USB 2.0and USB 1.1 devices.
5. Support the following speed data rates as follows: Low-speed (1.5Mbps) / Full-speed (12Mbps) / High-speed(480Mbps) / Super-speed (5Gbps).
6. Each USB port supplies maximum +5V 900mA power output to USB device.
7. Built-in 4-pin power connector for receiving extra power supply from system.
8. Hot-swapping feature allows you to connect/disconnect deviceswithout powering down the system.
9. Support Windows 7 / XP / 32 & 64 bit Vista / 98ES / DOS / Linux / 2008 / 2003.
Specification:
|
General
|
| Support System |
Windows XP, Windows 98SE, Windows Vista, Windows 7, Linux |
|
|
Package Include
|
| Package Contents |
1 x CD Driver
1 x Express Card |
|
|
Package Weight
|
| One Package Weight |
0.10kgs / 0.22lb
|
| Carton Weight |
7.28kgs / 16.05lb
|
| Carton Size |
46cm * 32cm * 32cm / 18.11inch * 12.6inch * 12.6inch
|
| Loading Container |
20GP: 566 cartons * 80 pcs = 45280 pcs
40HQ: 1314 cartons * 80 pcs = 105120 pcs
|
|
